Epoxy resin units

iMT spray systems

Technical specifications

  • Discharging amount approx. 5 - 15 l/min. Higher amounts on request
  • Variable mixing ratios
  • Flow meters to monitor the amount of material used
  • Continuous monitoring of forerun and return during production
  • Pressure monitoring with automatic safety switch-off
  • PLC with display for permanent control of amount, mixing ratio and temperature.
  • Automatic audible and visual empty signal
  • various containers possible: 200 l drums for A- and B component or permanently installed drums, 350 l A component and 250 l B component (in combination with a refilling station)
  • Electrically driven spindle pumps (pulsation free)
